Precision Sealing for Servo Motor Performance

The DMHUI BE6656F HTCY Oil Seal (24x66x6.6mm) is specifically designed for servo motor applications, delivering stable and reliable sealing in high-speed rotating environments. Built with NBR rubber and a double-lip structure, it helps protect internal components from oil leakage and external contaminants such as dust.

Engineered to match the requirements of FANUC servo motor A06B-0078-B403, this seal ensures consistent operation and supports long-term equipment performance.

Key Points

Designed for Servo Motor Applications
Optimized for precision equipment, especially compatible with FANUC servo motor systems, where stable sealing is essential for performance.

HTCY Double Lip Structure
Features a primary sealing lip combined with a secondary dust lip to help reduce contamination from external particles.

Dust-Resistant Performance
Helps protect internal components from dust and debris, making it suitable for industrial environments.

Durable NBR Rubber Material
Manufactured from nitrile rubber for reliable resistance to oils and lubricants while maintaining flexibility.

Compact Precision Fit
Accurate 24×66×6.6mm dimensions ensure proper installation and consistent sealing contact.

Product Info

Product Name: Rotary Shaft Oil Seal
OEM Part Number: BE6656F
Seal Type: HTCY (Double Lip with Dust Protection)
Material: Nitrile Rubber (NBR)
Dimensions:
Shaft (ID): 24mm
Bore (OD): 66mm
Width: 6.6mm
Primary Application: FANUC Servo Motor A06B-0078-B403
Package includes: 1 x BE6656F Oil Seal (24×66×6.6mm)

Servo motors require stable and consistent sealing to maintain performance. DMHUI designs sealing components to meet the demands of precision-driven equipment.

Double Lip Sealing Design
The primary lip maintains oil retention, while the secondary lip helps block dust and contaminants.

Elastic NBR Sealing Layer
Maintains flexibility during continuous rotation, helping reduce wear over time.

Secure Fit Structure
Ensures proper positioning within the housing for stable operation.

Ideal For Use In
Servo Motors:
FANUC servo motor systems and similar precision drive units
Automation Equipment:
CNC machinery, robotics, and automated production systems
Industrial Applications:
Equipment requiring compact, dust-resistant shaft sealing

FAQ

Q: Is this seal an exact match for my FANUC servo motor A06B-0078-B403?
A: Yes. This seal is manufactured to replicate the original BE6656F part, with dimensions 24x66x6.6mm and HTCY double-lip design, making it a direct fit for that specific FANUC servo motor model.

Q: What makes HTCY different from standard oil seals?
A: HTCY seals feature a double lip design, including a dust lip for additional protection.

Q: Can I use this seal on other equipment besides FANUC motors?
A: While designed specifically for the BE6656F application, it can be used in some rotary shaft application requiring a 24x66x6.6mm double-lip seal, provided the environment and fluids are compatible with NBR rubber. Always verify dimensions and working conditions first.

Q: How do I install this seal correctly?
A: Clean the shaft and housing thoroughly. Apply a light coat of clean grease or oil to the seal lip. Press the seal squarely into the housing bore using a flat installation tool, applying even pressure to the outer metal case only. The double-lip side should face outward (toward the external environment) to block dust.

Q: Do you offer other seals for FANUC servo motors?
A: Yes. We carry a range of seals for various FANUC motor models, including the BE6657F and other sizes. Please search our store or contact us with your specific part number.

Note: This product is an aftermarket replacement component. Verify the part number and dimensions from your original seal or equipment manual before ordering. Proper installation is essential for optimal sealing performance.

Trust in quality, choose DMHUI
Choose DMHUI sealing solutions designed for consistent performance in servo motor and automation systems. Built for accuracy, durability, and dependable operation.
